Frequency
Phase
Power
Power range
0.0
0.0
Model
SDG8500SSE
Single Phase | Air Cooled | Open Frame
Powered bySRGENSET
AlternatorSENCI
EmissionsNON CERTIFIED/ STAGE V
| PRP | ESP | |
|---|---|---|
| POWER kVA | 6 | 6.5 |
| POWER kW | 6 | 6.5 |
| Voltage | Frequency | Phase | Alternator |
|---|---|---|---|
| 110/220/230 | 50/60 | Single Phase | 204*130 |
| MODEL | SDG8500SSE | |||
|---|---|---|---|---|
| Rated frequency | Hz | 50 | 60 | |
| Rated voltage | V | 220, 230, 240, 110/220, 127/220, 115/230, 120/240, 220/380, 230/400, 240/415 | ||
| Rated power | Kw | 6 | 6.5 | |
| Max. power | Kw | 6.5 | 7.1 | |
| Phase number | Single phase / three phase | |||
| Excitation mode | Self-excitation and constant voltage (with AVR) | |||
| Power factor | cosΦ | 1.0(0.8) | ||
| Insulation grade | F | |||
| Fuel capacity | L | 15 | ||
| Noise Level@7m | dB(A) | 65 | 66 | |
| Engine model | SD192FE | |||
| Engine type | Single cylinder, 4-stroke, air cooled, vertical | |||
| Starting system | Electric start | |||
| Bore x stroke | mm | 92*75 | ||
| Displacement | L | 0.499 | ||
| Compression ratio | 20:1 | |||
| Rated rotation speed | rpm | 3000/3600 | ||
| Rated power | kW | 7.6/8.6 | ||
| Lube oil capacity | L | 1.65 | ||
| Fuel type | DIESEL: 0＃（summer）-10＃（winter）-35＃（chillness） | |||
| Lube oil type | About CD grade or SAE 10W-30、15W-40 | |||
| Optional | ATS | |||
| Remote control | ||||
| Digital smart panel | ||||
| Overall dimension(L*W*H) | mm | 995*645*890 | ||
| Net weight | kg | 175 | ||
