Weichai Generator Series

Weichai Series

The diesel generator set is equipped with Weichai’s diesel engine.

· Standby Power:18KW-1600KW

· Type: Open/Silent/Super Silent/Mobile Trailer

· MOQ:1 Set

Standby（KW）	Engine Model	Motor-Nianfeng	Silent Model
18	WP2.3D25E200	184L-E	Slience
25	WP2.3D33E200	184L-G	Slience
30	WP2.3D40E200	184L-H	Slience
36	WP2.3D48E200	224L-D	Slience
50	WP4.1D66E200	224L-E	Slience
60	WP4.1D80E200	224L-F	Slience
80	WP4.1D100E200	274L-C	Slience
100	WP6D132E200	274L-D	Slience
120	WP6D152E200	274L-FS	Slience
136	WP6D167E200	274L-G	Slience
160	WP10D200E200	274L-H	Slience
180	WP10D238E200	274L-J	Slience
200	WP10D264E200	274L-K	Slience
250	WP10D320E200	4L-ES	Slience
300	WP13D385E200	4L-FS	Slience
320	WP13D405E200	4L-F	Slience
350	WP13D440E310	5L-C	Slience
400	WP13D490E310	5L-D	Slience
450	6M33D572E200	5L-E	Slience
520	6M33D633E200	5L-G	Slience
540	6M33D670E200	5L-G	Slience
600	6M33D725E310	6L-B	20-foot container
640	12M26D792E200	6L-C	20-foot container
720	12M26D902E200	6L-D	20-foot container
800	12M26D968E200	6L-E	20-foot container
900	12M33D1108E200	6L-F	20-foot container
1000	12M33D1210E200	6L-G	20-foot container
1100	12M33D1320E200	7L-B	40-foot container
1200	12M33D1500E310	7L-C	40-foot container
1240	16M33D1530E310	7L-C	40-foot container
1300	16M33D1580E310	7L-D	40-foot container
1400	16M33D1680E310	7L-E	40-foot container
1500	16M33D1800E310	7L-E	40-foot container
1600	16M33D1980E310	7L-F	40-foot container

Standy(kw)	Engine Model	Motor-Nianfeng	Silent Model
20	WP2.3D30E201	184L-E	Slience
30	WP2.3D41E201	184L-G	Slience
35	WP2.3D47E201	184L-H	Slience
40	WP2.3D58E201	224L-C	Slience
60	WP4.1D80E201	224L-E	Slience
72	WP4.1D95E201	224L-F	Slience
90	WP4.1D115E201	274L-C	Slience
100	WP6D132E201	274L-DS	Slience
120	WP6D158E201	274L-D	Slience
144	WP6D180E201	274L-FS	Slience
150	WP10D200E201	274L-F	Slience
180	WP10D238E201	274L-G	Slience
192	WP10D264E201	274L-H	Slience
240	WP10D360E201	274L-K	Slience
300	WP13D385E201	4L-E	Slience
320	WP13D448E201	4L-F	Slience
350	WP13D460E311	4L-G	Slience
400	WP13D510E311	5L-C	Slience
500	6M33D633E201	5L-E	Slience
520	6M33D670E201	5L-E	Slience
540	6M33D710E201	5L-E	Slience
600	6M33D740E311	5L-F	20-foot container
Units larger than 600kW and 60Hz, negotiable per order.

Generator Set Parameters - Weichai Engine

Engine

Fuel Consumption per hour

190-250g/kWh

Diesel Generator Set

Phase	AC Three Phase
Power Factor (cosΦ)	0.8(lag)
Fuel Tank Capacity	100L-10000L
Noise Level	≤75 db
Type	Open,Slient(Super Slient),Protable,Containerized
Color	Customization available
Certification	ISO9001/ISO14001/CE/E49
Warranty	One Year/1000 Running Hour

Diesel Generator Manufacturers

SRGENSET is a diesel generator set manufacturer in China. We help our customers obtain reliable mains/emergency power sources by providing reliable power supply solutions for various applications.

· Advanced Diesel Generator Production Line

· Independent design and assembly, supporting customer customization.

· A rigorous review process ensures high-quality diesel generators.

Generator Set Structure

Slient Diesel Generator Set

Open Diesel Generator Set

Characteristics

Canopy

The canopy is compact and strong, reducing space occupation, suitable for various application places.

High Level Rust Proof Technology

Three layers of anti rust coating (electrophoretic, two layers of spray coating)

Noise Cancellation

Standard 30 mesh sponge effectively reduces engine running noise by 20-30dBA

Muffler

High performance muffler with a maximum noise reduction effect of over 25dBA

Bounded Fuel Tank

Bounded fuel tank to prevent liquid leakage, the internal structure of the tank is designed to prevent surge and is better for safe transporta- tion. The large capacity tank provides more than 12 hours of generator running.

Moving & Transportation

Forklift hole,lifting rods& hock holes,pull rod are convenient for the generator movement and transportation.

Output Terminals & Sockets

Output terminals & multi sockets are easly and conveniently adapted to various power output connections.

Rental Generator Design

Outdoor rainproof and rustproof canopy, strong chassis suitable for rental generator applications.

Certification

FAQ

Are you a diesel generator set manufacturer?

Yes, SRGENSET is a diesel generator manufacturer, and we have our own production plant in Huai’an City, Jiangsu Province, China.

What power rating of diesel generator do you provide?

SRGENSET offers diesel generators with power ranging from 5 to 2000 kW, primarily operating at frequencies of 50 Hz and 60 Hz.

Do you support custom diesel generators?

Yes, SRGENSET supports custom diesel generator services. We have a large stock of frequently customized parts, and you can discuss specific details with our engineers.

Does your factory have certification?

SRGENSET holds numerous certifications, including ISO 9001, ISO 14001, ISO 45001, and other factory certifications, as well as E49, CE, ICG, and other product certifications.

What is the normal delivery time?

SRGENSET maintains a small stock of standard models. If you require a small quantity of these models, we can ship them to you within a week. If you need bulk orders or customized products, we typically ship within 30-40 days.
